| Business Type | Supplier, Retailer, Trader |
| Customization | Professional LED RGBW Flood Light |
| Light Color | RGBW (Red, Green, Blue & White) |
| Packaging | Box |
| Click to view more | |
Product Details
Finish Options
UV-Stable Pure Polyester Powder Coating
Payment Mode
All Payment Received Mode
Maximum Drive Current
Current Driver
Type
Professional LED RGBW Flood Light
Light Source
High-Power RGBW LEDs
Control Protocol
DMX512 Compatible
Programming
Supports Dynamic Lighting Scenes, Color Mixing, Dimming & Effects
Input Voltage
AC 100–240 V
Frequency
50/60 Hz
Power Factor
≥ 0.90
Color Output
RGBW (Red, Green, Blue & White)
CRI
≥ 80
Beam Angle
10°, 15°, 30°,45°or 60° (Model Dependent)
Lens Material
High-Transmission Optical Polycarbonate (PC) Lens
LED Lifetime
≥ 50,000 Hours (L70)
Driver
Built-in Constant Current Electronic LED Driver
Driver Protection
Short Circuit, Over Voltage & Over Current Protection
Housing Material
High-Strength Die-Cast Aluminum
Surface Finish
UV-Stable Pure Polyester Powder Coating
Housing Color
Standard Grey (RAL 7040 or Equivalent)
Thermal Management
High Thermal Conductivity Aluminum Body with Integrated Cooling Fins
Protective Glass
Ultra-White Tempered Safety Glass
Impact Resistance
IK07
Ingress Protection
IP66 Luminaire with IP68 Cable Gland
Sealing
Multi-Layer Silicone Rubber Gasket System
Mounting
Adjustable Heavy-Duty Mounting Bracket
Operating Temperature
-20°C to +50°C
Storage Temperature
-30°C to +70°C
Installation
Outdoor Wall, Facade, Landscape, Architectural & Flood Lighting
Warranty
2 Years (Project Dependent)
Product Code
NS Brothers-2010
Delivery Time
10-15 working day
Construction Features
- High-strength lightweight die-cast aluminum housing
- Corrosion-resistant pure polyester powder-coated finish
- Excellent heat dissipation through integrated thermal fins
- Ultra-white tempered safety glass for maximum light transmission
- High-performance optical PC lens for precise beam control
- Premium silicone sealing system for long-term weather resistance
- Stainless steel external hardware for corrosion resistance
- IP66-rated luminaire with IP68-rated cable gland
- High-efficiency RGBW LED module
- Smooth RGBW color mixing
- Uniform illumination without visible color separation
- Available beam angles:
- 10° – Narrow Spot
- 15° – Spot
- 30° – Flood
- Flicker-free operation
- Excellent color consistency
- Wide operating voltage: AC 100–240V
- DMX512 digital control protocol
- Constant current electronic LED driver
- High power factor (≥0.90)
- Protection against:
- Short Circuit
- Over Voltage
- Over Current
- Stable performance under voltage fluctuations
